Airmar CM599LH 1-3 kW Pocket Mounted Transducer for Deep-Water Fishing and Commercial Marine Use

CM599LH 1-3kW Pocket Mounted Transducer - No Connector

Having the right tool for the job makes the job easier and gives better results. The right tool for covering deep-water haunts of swordfish, tuna, and other species is a 2 to 3 kW, low and high-frequency transducer. The Chirp-ready CM599LH gives the deep-water performance of the low frequency down to 3000 m (10000) plus the incredible resolution that the high-frequency band delivers.

The CM599LH is packed with a twenty-four-element, low-frequency array that operates at anywhere between 28 and 60 kHz. The single, high-frequency ceramic operates at any frequency between 130 and 210 kHz and has a narrow, 8 to 4, beamwidth.

Features:

• Depth and fast-response water-temperature sensing
• 2 to 3 kW of power for exceptional deep-water performance
• Low frequency: 28 to 60 kHz
• 23 to 9 port-starboard beamwidth
• 11 to 5 fore-aft beamwidth
• Maximum depth to 3048 m (10000)
• High frequency: 130 to 210 kHz
• 8 to 4 beamwidth
• Maximum depth to 457 m (1500)
• 112 kHz of total bandwidth from one transducer
• Covers popular fishing frequencies of 50 and 200 kHz plus everything else in the bandwidth
• Resin housing with curved-edge design for wet-box installation
• Can be installed in a cavity or welded tank
• Also available as thru-hull external (R509LH) and in-hull (R599LH) mounts
• Patented Xducer ID technology

Specifications:

• Frequency Band: Low-High
• Functions:Depth, Temperature
• Material:Urethane
• Mounting Style:Tank, Cavity, Pocket/Keel Mount
• Connector:Bare Wire
• Display Connector:0
• Hull Material:Fiberglass or metal
• Max Vessel LOA:8 m (25) and above
• High Frequency:130-210 kHz
• Common Use:Fishing, Commercial Fishing
• Max Deadrise Angle:Any
• Tilted Element:No
• Low Frequency Beamwidth:11x23-5x9
• Low Frequency:28-60 kHz
• High Frequency Beamwidth:8-4
• Max Deadrise:Accommodates any deadrise angle based on custom installation
• Power Rating:2-3 kW
• Single or Dual Frequency:CHIRP-Ready Dual-Band
• Country of Origin:USA
• Cable-Length:15 m (49)
• Weight:14.2 kg (31.2 lb.)
• Max Depth: Low frequency- 3048 m (10000), High frequency- 457 m (1500)

The Airmar CM599LH is a high-performance, Chirp-ready transducer designed for serious deep-water anglers and commercial vessels. With a power range of 2 to 3 kW, this transducer offers exceptional performance at depths up to 10,000 feet, making it ideal for covering the deep-water haunts of swordfish, tuna, and other large pelagic species. Its dual-band operation includes a low-frequency array spanning 28 to 60 kHz and a high-frequency ceramic from 130 to 210 kHz, providing versatile coverage and detailed resolution across a broad spectrum of fishing conditions. The low-frequency array features a twenty-four-element design with a beamwidth of approximately 11 by 23 degrees, while the high-frequency element offers a narrow 8 by 4-degree beam, ensuring precise target detection in challenging environments. This transducer also includes depth and water temperature sensing, which enhances fishing efficiency and vessel navigation. Constructed with a durable resin housing and a curved-edge design, the CM599LH is suitable for wet-box installation, can be mounted in a cavity or welded tank, and can be adapted for external or in-hull mounting options, including the optional R509LH and R599LH models. Its 15-meter cable length provides flexible installation options, and the patented Xducer ID technology simplifies setup and calibration. Made in the USA, this transducer is compatible with vessels up to 25 feet or larger, accommodating any deadrise angle for custom installation. Whether used for recreational or commercial fishing, the Airmar CM599LH delivers reliable, high-resolution sonar imaging at extreme depths, making it an essential tool for serious deep-water anglers and commercial operators alike. Note that this product may not be returned to the original point of purchase, and customers are advised to contact the manufacturer directly for any issues or concerns.

Features:

• Depth and water temperature sensing for real-time data

• Power output of 2 to 3 kW for superior deep-water performance

• Low frequency range: 28 to 60 kHz with broad beamwidth for broad coverage

• High frequency range: 130 to 210 kHz with narrow beamwidth for detailed imaging

• Maximum depth rating: 10,000 feet (3,048 meters) at low frequency

• Maximum depth rating: 1,500 feet (457 meters) at high frequency

• 112 kHz total bandwidth covering popular fishing frequencies of 50 and 200 kHz

• Durable resin housing with curved-edge design for wet-box installation

• Flexible mounting options: cavity, tank, pocket, or keel mount

• Patented Xducer ID technology for easy setup and calibration

• Made in the USA with high-quality materials for reliability and longevity
