ASEA Power Systems 12 kVA Isolation Transformer for Marine Safety and Power Stability

12 kVA Isolation Transformer

ASEAs Isolation Transformer is a drop-in replacement for Charles IsoG2, designed to protect vessel under-fittings from galvanic corrosion and to shield onboard electronics from reverse polarity and shore power fluctuations. It also ensures safety by preventing the boat from sending unintended electric currents into the surrounding water.

Features:

• Ignition-protected, safe for gasoline-powered vessels
• Complete Electrical Isolation prevents dockside ELCI breaker trips
• Maintains a safer marine environment by mitigating the risk of ESD
• Ensures clean and stable AC power for on-board equipment
• Reduces galvanic corrosion
• Meets the latest NEC 555.35 marina code that ensures GFPE limits are not exceeded

Specifications:

• Input Voltage: 240VAC
• Input Current: 50 A
• Output Voltage: 240VAC
• Output Current: 50 A
• Output Frequency: 60 Hz
• Weight 160 lbs
• Height: 27cm / 10.6 in
• Width: 26cm / 10.2 in
• Width (with flange): 33 cm / 13 in
• Depth: 26.7 cm / 10.5 in

Certifications:

• ABYC E-11 Compliant
• ABYC C-1500 (for ignition protection)
• UL 1500 (for ignition protection)
• UL 1561

The ASEA Power Systems 12 kVA Isolation Transformer is a vital component for ensuring safe and reliable power on your vessel. Designed as a drop-in replacement for the Charles IsoG2, this transformer provides complete electrical isolation to protect onboard electronics from power fluctuations, reverse polarity, and shore power issues. Its robust construction and advanced features help prevent galvanic corrosion, extending the lifespan of vessel under-fittings and maintaining a safer marine environment.

Built with safety and compliance in mind, the ASEA 12 kVA Isolation Transformer is ignition-protected, making it suitable for gasoline-powered boats and compliant with the latest NEC 555.35 marina code, ensuring that GFPE limits are not exceeded. The transformer maintains a stable and clean AC power supply to onboard equipment, reducing the risk of electrical disturbances such as electrostatic discharge (ESD) and power surges. Its complete electrical isolation also prevents nuisance trips of dockside ELCI breakers, facilitating smoother dockside operations and enhanced safety.

This transformer features a 240VAC input and output with a 50A capacity, operating at 60Hz. Weighing approximately 160 lbs, it offers durable performance with dimensions designed for easy installation on a variety of vessel types. Its compact footprint and flange options make integration straightforward, while its UL and ABYC certifications assure compliance with marine safety standards. For detailed installation instructions, refer to the owner’s manual available online. Investing in the ASEA Power Systems 12 kVA Isolation Transformer ensures your vessel’s electrical system remains stable, safe, and compliant with marine safety regulations, providing peace of mind during every voyage.

Features:

• Ignition-protected, safe for gasoline-powered vessels

• Complete electrical isolation prevents dockside ELCI breaker trips

• Maintains a safer marine environment by mitigating the risk of electrostatic discharge (ESD)

• Ensures clean and stable AC power for onboard equipment

• Reduces galvanic corrosion to prolong vessel component life

• Meets NEC 555.35 marina code requirements for GFPE limits
