Egis Mobile Electric Triple Battery Advanced Automatic Charging Relay (ACR) - 24V

Triple Battery Advanced Automatic Charging Relay (ACR) - 24V

Two Independent ACRs in One Device reduce installation space and time. Significantly lowers the out-of-state current draw.

Features:

• Eliminates Dead Start Batteries by sharing charge sources with all batteries and isolating batteries when no charge sources are present
• Simple Robust Installation:Integrated sealed plug eliminates corrosion, includes DT04 harness. A single device reduces installation time, space, cost, and points of potential failure
• An additional low-amp output can be used to report device status remotely.
• Bullet-proof Construction: Sealed unit, high-temperature materials allow mounting anywhere. Integrated thermal overload shutdown protection
• Ultra Low Off-State Current: Compare two typical ACRs (20 mA) vs Dual ACR @ 1.3 mA
• Adjustable Off-Voltage for Auxiliary Battery Priority provides the ability to share start battery energy for auxiliary without risking engine starting ability.
• Start/Engine Isolation input option for ensuring sensitive electronics do not experience voltage sags and spikes from the cranking event.
• Start Assist input option to ensure maximum cranking amps available when necessary.
• 4 Year Industry-Leading Warranty

The Egis Mobile Electric Triple Battery Advanced Automatic Charging Relay (ACR) for 24V systems offers a compact and reliable solution for managing multiple batteries efficiently. Designed with two independent ACRs within a single device, this unit reduces installation time and space requirements while ensuring optimal battery charging. The advanced circuitry significantly lowers out-of-state current draw, helping to preserve battery life and improve overall vehicle electrical system performance. This versatile relay eliminates dead start batteries by sharing charge sources across all batteries and isolating batteries when no charge sources are present, ensuring your vehicle is always ready to start. The Egis ACR features a simple, robust installation with an integrated sealed plug that resists corrosion, complemented by a DT04 harness for easy wiring. Its sealed construction allows mounting in any environment, including high-temperature areas, thanks to durable, heat-resistant materials and integrated thermal overload shutdown protection. An additional low-amp output provides remote status reporting, enabling better system monitoring. The ultra-low off-state current of just 1.3 mA, compared to typical ACRs at 20 mA, conserves battery power during idle periods. Adjustable off-voltage settings allow you to prioritize auxiliary batteries without risking engine start capability, adding flexibility to your electrical system management. The start/engine isolation feature protects sensitive electronics from voltage fluctuations during cranking, while the start assist input ensures maximum cranking amps when needed. Built with durability in mind, the Egis Triple Battery ACR comes with an industry-leading 4-year warranty, making it a dependable choice for commercial and recreational vehicle applications. Whether you're upgrading your existing electrical system or installing a new setup, this advanced relay provides peace of mind, efficient battery management, and simplified installation in a compact form factor.

Features:

• Eliminates dead start batteries by sharing charge sources and isolating batteries when no charge is available

• Simple, robust installation with integrated sealed plug and DT04 harness for corrosion resistance and ease of wiring

• Includes an additional low-amp output for remote device status monitoring

• Sealed construction with high-temperature materials and thermal overload shutdown for versatile mounting

• Ultra-low off-state current of 1.3 mA conserves battery power during idle periods

• Adjustable off-voltage for auxiliary battery priority to ensure reliable engine starts

• Start/engine isolation input protects sensitive electronics from voltage sags and spikes during cranking

• Start assist input to maximize cranking amps when necessary

• Industry-leading 4-year warranty ensures long-term reliability and peace of mind
