Egis Mobile Electric XD Flex 1 Single Relay/ACR without Knob - 6-Pin DTM Connector

XD Flex 1 Single Relay/ACR without Knob - 6-Pin DTM Connector

Features:

• 500 Amp Continuous Capability Per Relay / Extremely Compact Footprint
• Available with or Without Intuitive Front Facing Manual Override Knob with the ability to Lock Relays ON or OFF for Servicing
• Flexible Functionality via Dip Switches, utilize each as a Relay/Battery Disconnect, Automatic Charging Relay, or Low Voltage Disconnect
• Supports Single/Multiple Engine Installations with Dual Start/Engine Isolation Inputs
• Remote ON/OFF/Auto Inputs allow forced close or open, or allow automatic operation based on Voltage Sensing
• Local and Remote LED Indicators for Each Relay

The Egis Mobile Electric XD Flex 1 Single Relay/Automatic Charge Relay (ACR) is engineered to deliver high-performance switching with a compact design, making it ideal for a variety of vehicle applications. This relay features a robust 500 Amp continuous capability, ensuring reliable operation even under demanding conditions. Its compact footprint allows for flexible installation in tight spaces, providing efficient power management without sacrificing performance. The relay's design includes an optional front-facing manual override knob, which can be locked in the ON or OFF position for safe servicing and maintenance, offering added convenience and safety during installation and troubleshooting.

Designed for versatility, the Egis XD Flex 1 incorporates flexible functionality through configurable dip switches. It can serve as a relay for battery disconnects, automatic charging, or low voltage protection, adapting easily to different electrical system needs. Supports single or multiple engine configurations with dual start and engine isolation inputs, making it suitable for complex vehicle setups.

Remote control capabilities are built-in with support for remote ON/OFF/Auto inputs, enabling automatic operation based on voltage sensing or manual forced actions. Local and remote LED indicators for each relay provide clear status updates, simplifying diagnostics and system monitoring. The durable 6-pin DTM connector ensures a secure connection, and the absence of a knob allows for streamlined integration into modern vehicle electrical systems.

Whether used in commercial trucks, RVs, or specialized vehicles, the Egis XD Flex 1 Single Relay/ACR offers a reliable, flexible, and space-efficient solution for managing electrical loads and ensuring optimal power distribution across multiple systems. Its combination of high current capacity, configurable features, and remote control options makes it an essential component for advanced vehicle electrical systems.

Features:

• 500 Amp continuous current capacity for reliable power switching

• Available with or without manual override knob, lockable for safety during servicing

• Configurable via dip switches for relay, battery disconnect, automatic charging, or low voltage disconnect functions

• Supports single or multiple engine installations with dual start and engine isolation inputs

• Remote control inputs for automatic or manual operation, including forced close or open commands

• Local and remote LED indicators for real-time relay status monitoring
