Humminbird HELIX 7 CHIRP MEGA DI GPS G4N Fish Finder with 7-Inch Display, Internal GPS, and Dual Spectrum CHIRP Sonar

HELIX 7 CHIRP MEGA DI GPS G4N

The HELIX 7 CHIRP MEGA DI GPS G4N fish finder features MEGA Down Imaging, Dual Spectrum CHIRP Sonar, AutoChart Live, Internal GPS, and Humminbird Basemap built-in. An upgraded high-definition 7" display will give you the best view of the many pre-loaded split screen view options so that you'll never miss a fish. All HELIX 7 G4N models support Ethernet networking, Bluetooth(R), NMEA 2000(R), Wi-Fi, and are compatible with the One-Boat Network(TM), which means you'll have total control of your fishing machine at your fingertips.

Features:

• Keypad control: Master HELIX at the touch of a button. Access the pre-loaded views from the user-friendly menu system, operated by softkey controls that allow you to reliably operate your fish finder in any conditions.
• MEGA Down Imaging: Get unprecedented underwater clarity with coverage down to 125 feet below your boat. You'll unlock new details with up to 3X more detail than standard Down Imaging sonar.
• Dual Spectrum CHIRP sonar: Before you cast, know what's down there thanks to highly detailed fish arches and a clear view of the fish-holding structure and the bottom. Powered by our proprietary, Low-Q CHIRP transducer, Dual Spectrum CHIRP 2D sonar offers two ways to search; Wide Mode for maximum coverage and Narrow Mode for focusing on the slightest detail.
• Internal GPS and Humminbird Basemap: Our enhanced base map provides you with a clear view of underwater terrain and surrounding points of interest so you can fish and navigate with total confidence. Identify buoys, day markers, hazards, marinas, contours, depth markers, and much, much more. Includes charts of more than 10,000 lakes, plus coastal coverage for the continental U.S.
• Premium Chart Compatible: Humminbird provides the most complete offering of premium chart options to anglers everywhere. Get a complete view of the world below with optional charts from Humminbird's LakeMaster and CoastMaster products, as well as your choice of compatible Navionics charts.
• AutoChart Live: Create real-time maps of your fishing spots, with access to patented Humminbird LakeMaster features. Map depth contours, bottom hardness and vegetation as you drive your boat. Comes standard with eight (8) hours of built-in recording time and is compatible with AutoChart Zero Line SD cards for virtually-endless AutoChart Live mapping capacity.
• One-Boat Network Compatible: These Humminbird models seamlessly integrate and communicate with other Humminbird and Minn Kota products to unlock more features and capabilities for anglers everywhere. Make the more of your time on the water with the exclusive boat control and fish-catching features of the One-Boat Network.
• Ethernet Networking: High-speed Ethernet allows you to build a powerful, professional-grade fishing system. Easily connect multiple fish finders, or upgrade to add-on technologies like Minn Kota i-Pilot Link and Humminbird CHIRP Radar.
• Bluetooth: Take control right from the screen of your Humminbird with wireless communication to compatible Talon and Raptor shallow water anchors. Additional features include wireless software updates from the Humminbird FishSmart App and a display of smartphone notifications on your Humminbird.
• NMEA 2000 networking built-in: Connect an accessory NMEA 2000 network to your control head for even more information; from boat performance to weather and water conditions, make sense of it all with NMEA 2000 networking.
• Includes control head, transom-mount transducer, power cable, gimbal mounting bracket, and mounting hardware.
• 1-Year Limited Warranty

Specifications:

• Display Size - Diagonal: 7"
• Display Pixel Matrix: 1024H x 600V
• Sonar-Standard: Dual Spectrum CHIRP, MEGA Down Imaging
• Sonar-Coverage: 20, 42, 60 (2) 86 @ -10dB
• Sonar-Optional: 53 kHz, 50/Low Airmar CHIRP
• CHIRP - Frequencies Supported: 83/200 (75-155/130-250 kHz), Full Mode (150-220 kHz), Narrow Mode (180-240 kHz), Wide Mode (140-200 kHz)
• Sonar-Frequencies Supported: 50/83/200/455/800 kHz 1.2 MHz
• Depth-Sonar: 1,200 ft (standard transducer), 3,500 ft (optional 50 kHz)

The Humminbird HELIX 7 CHIRP MEGA DI GPS G4N is a powerful and versatile fish finder designed for serious anglers seeking precision and clarity on the water. Featuring a bright 7-inch high-definition display with a 1024H x 600V pixel matrix, this device offers an exceptional view of underwater structures, fish, and terrain, making every trip more productive. The advanced MEGA Down Imaging provides unprecedented clarity down to 125 feet, revealing up to three times more detail than traditional sonar, enabling you to identify fish-holding structures and underwater features with ease. Dual Spectrum CHIRP Sonar technology delivers highly detailed images with wide and narrow modes, giving you two search options to optimize your fishing strategy. The device's internal GPS and Humminbird Basemap provide detailed charts of over 10,000 lakes and coastal areas across the continental US, ensuring confident navigation and spot marking. The built-in AutoChart Live feature allows anglers to create real-time maps of their favorite fishing spots, mapping depth contours, bottom hardness, and vegetation, with up to eight hours of recording capacity. Seamlessly integrated with the One-Boat Network, the HELIX 7 G4N supports Ethernet, Bluetooth, NMEA 2000, and Wi-Fi connections, allowing you to connect with compatible Minn Kota trolling motors, Radar, and other accessories for a comprehensive boat control system. The keypad control system ensures intuitive operation in any conditions, while wireless features enable control of compatible shallow water anchors and software updates via the FishSmart App. Complete with transom-mount transducer, power cable, mounting hardware, and a one-year limited warranty, the Humminbird HELIX 7 G4N is the ultimate tool for anglers who demand precision, connectivity, and clarity in their fishing experience.

Features:

• Keypad control for reliable, easy operation with pre-loaded split screen views

• MEGA Down Imaging provides detailed underwater views down to 125 feet

• Dual Spectrum CHIRP Sonar with Wide and Narrow modes for targeted fish detection

• Internal GPS and Humminbird Basemap for accurate navigation and mapping

• AutoChart Live for creating real-time maps of fishing spots, with eight hours of recording

• Supports Ethernet, Bluetooth, NMEA 2000, and Wi-Fi for seamless connectivity

• Compatible with Humminbird LakeMaster, CoastMaster, and Navionics premium charts

• Supports One-Boat Network for integrated boat control and fish-finding capabilities

• Built-in NMEA 2000 network for additional data and accessory integration

• Includes control head, transom-mount transducer, power cable, mounting hardware, and manual
