Mastervolt CombiMaster 12V 3500W 200A Inverter/Charger 120V, Part Number 35513500

CombiMaster Inverter/Charger - 12/3500-200 Amp - 120V

The CombiMaster inverter/charger provides the most power and charging in the series. The 3500W version comes in 12V and can be paralleled stacked in a single system up to 10.5kW. The 24V models in 3500W and 5000W can create parallel stacked systems up 35kW. The 1500W version delivers 1500W of pure sine wave inverter power and 60 amps multi chemistry battery charging. The 1500W is the smallest form factor in the series. All models provide pure sine wave inverter power and over 60-200 amps multi-chemistry battery charging, plus the intelligent design is NMEA 2K and MasterBus compatible.

Specifications:

• Nominal DC Voltage: 12V (10.2-16V)
• Continuous Power at 104 F: 3500W
• Peak Power 30 seconds: 5250W
• Surge Power 5 seconds: 7000W
• Parallel Stacking: Yes, Up to 3
• Synchronize with Mains/Generator: Yes
• Output Waveform: Pure Sine

Mastervolt CombiMaster 12V 3500W 200A Inverter/Charger delivers high-capacity pure sine wave inverter power and multi-chemistry battery charging for demanding onboard electrical systems. Designed for applications requiring dependable 120V AC power and substantial battery charging capability, this CombiMaster model combines inverter and charger functions in one integrated unit.

Operating from a nominal 12V DC system, the CombiMaster provides 3500 watts of continuous power at 104°F, with 5250 watts of peak power for up to 30 seconds and 7000 watts of surge power for up to 5 seconds. Its pure sine wave output is suitable for powering compatible AC equipment, while the 200-amp multi-chemistry battery charger supports efficient replenishment across compatible battery chemistries. The unit can also synchronize with mains or a generator, helping integrate it into appropriately configured electrical systems.

For larger power requirements, the 12V 3500W CombiMaster supports parallel stacking of up to three units. Its intelligent design is compatible with NMEA 2K and MasterBus systems, providing integration options for marine and other compatible power-management applications. The Mastervolt CombiMaster is intended for professional system builders, marine electrical installations, and users who need a high-output inverter/charger for a 12V battery bank.

Key Features

• 3500W continuous inverter power: Supplies high-capacity 120V AC power from a 12V DC battery system.
• Pure sine wave output: Produces a pure sine waveform for compatible AC equipment.
• 200A multi-chemistry battery charging: Supports high-capacity charging for compatible battery chemistries.
• High surge capability: Provides 5250W of peak power for 30 seconds and 7000W of surge power for 5 seconds.
• Parallel stacking: Supports connecting up to three units for expanded system power.
• System integration: Compatible with NMEA 2K and MasterBus systems and can synchronize with mains or a generator.

Product Details

• Brand: Mastervolt
• Model/Part Number: 35513500
• Product type: Inverter/charger
• Nominal DC voltage: 12V, with an operating range of 10.2–16V
• AC output voltage: 120V
• Continuous power at 104°F: 3500W
• Peak power: 5250W for 30 seconds
• Surge power: 7000W for 5 seconds
• Output waveform: Pure sine
• Parallel stacking: Yes, up to three units
• Mains/generator synchronization: Yes

Choose the Mastervolt CombiMaster 12V 3500W 200A Inverter/Charger for a powerful, integrated solution for compatible 120V AC power and high-capacity battery charging systems.
