Mastervolt CombiMaster 24/3500-100 Amp 120V Pure Sine Wave Inverter/Charger, Part 35523500

CombiMaster Inverter/Charger - 24/3500-100 Amp - 120V

The CombiMaster inverter/charger provides the most power and charging in the series. The 3500W version comes in 12V and can be paralleled stacked in a single system up to 10.5kW. The 24V models in 3500W and 5000W can create parallel stacked systems up 35kW. The 1500W version delivers 1500W of pure sine wave inverter power and 60 amps multi chemistry battery charging. The 1500W is the smallest form factor in the series. All models provide pure sine wave inverter power and over 60-200 amps multi-chemistry battery charging, plus the intelligent design is NMEA 2K and MasterBus compatible.

Specifications:

• Nominal DC Voltage: 24V (10.2-16V)
• Continuous Power at 104 F: 3500W
• Peak Power 30 seconds: 4500W
• Surge Power 5 seconds: 6000W
• Parallel Stacking: Yes, Up to 7
• Synchronize with Mains/Generator: Yes
• Output Waveform: Pure Sine

The Mastervolt CombiMaster 24/3500-100 Amp 120V inverter/charger combines high-output pure sine wave inverter power with multi-chemistry battery charging for marine, mobile, and other 24V power systems. Designed for applications requiring dependable AC power and substantial charging capacity, this 3500-watt model supports synchronized operation with mains or a generator and can be configured in parallel for expanded system capacity.

With 3500 watts of continuous power at 104°F, the CombiMaster delivers up to 4500 watts of peak power for 30 seconds and 6000 watts of surge power for 5 seconds. Its pure sine wave output is suited to powering sensitive electronic equipment and standard AC loads, while the integrated charger supports efficient battery replenishment. The intelligent design is compatible with NMEA 2K and MasterBus systems, making it a practical choice for connected power installations.

The 24V CombiMaster can be parallel stacked with up to seven units, allowing system builders to scale available inverter capacity for larger power requirements. It also synchronizes with mains power or a generator to support flexible operation in demanding installations. Mastervolt part 35523500 provides a combined inverter and charger solution for customers seeking robust 24V power conversion in a single unit.

Key Features

• Pure sine wave inverter: Provides clean AC power for compatible electrical equipment and electronics.
• 3500-watt continuous output: Delivers substantial inverter capacity at 104°F for 24V power systems.
• High surge capability: Supplies up to 4500 watts for 30 seconds and 6000 watts for 5 seconds.
• Parallel stacking: Supports up to seven units for expanded system capacity.
• Mains and generator synchronization: Enables coordinated operation with utility or generator power sources.
• System compatibility: Intelligent design is compatible with NMEA 2K and MasterBus.

Product Details

• Brand: Mastervolt
• Part number: 35523500
• Product type: Inverter/charger
• Nominal DC voltage: 24V
• Continuous power at 104°F: 3500W
• Peak power: 4500W for 30 seconds
• Surge power: 6000W for 5 seconds
• Output waveform: Pure sine
• Parallel stacking: Up to 7 units
• Input synchronization: Mains/generator compatible
• Overall size: Approximately 23 inches long by 23 inches wide by 10 inches high
• Weight: Approximately 145 pounds

Choose the Mastervolt CombiMaster 35523500 for integrated 24V pure sine wave inverter power and battery charging in a scalable, connected system.
