Pacer TDT04F-2RP DT Deutsch Receptacle Repair Kit, 2-Position, 14–18 AWG

DT Deutsch Receptacle Repair Kit - 14-18 AWG (2 Position)

Pacer's DT repair kits use the larger size 16 contacts (Deutsch Pin P/N 0460-215-16141, Socket P/N 0462-209-16141) for applications using 14 AWG wire. However, DT series connectors are designed for 18-14 wire gauge applications. The DT series offers electrical designers the ability to use multiple sizes of 16 contacts (18-14 AWG) each with a 13-amp continuous capacity, within a single shell. Pacer also sells these other components for use in a wider range of applications.

Features:

• Packs include all parts needed to assemble a connector
• One to two extra terminals
• Cavity plugs to seal open circuits

Applications:

• Wire-to-wire applications
• Enclosed connectors offer field-proven reliability and rugged quality

Compliances:

• Ingress Protection (IP) Level: IP68 and IP6K9K
• EU RoHS/ELV
• Standard UL-94 Recognized

Characteristics:

• Wedge locks ensure contact alignment and retention
• Redundant Silicone Seals
• Hand-insertable and removable contacts

Technical Specifications:

• Number of Cavities: 2
• Housing: Rectangular receptacle, plastic reinforced with glass fiber
• Contact Size: 16 (13 amp)
• Wire Size: 14 AWG
• Holds Pin/Socket: Pins
• Operating Temperature: -55C to 125C

Contents:

• (1) 2 pos. receptacle
• (1) 2 pos. wedge lock
• (3) pins

Pacer TDT04F-2RP DT Deutsch Receptacle Repair Kit provides the components needed to assemble or repair a 2-position DT series wire-to-wire connector for 14–18 AWG applications. Designed around size 16 contacts with a 13-amp continuous capacity, this kit is suited for electrical systems that require reliable contact alignment, retention, and sealed connector construction.

The kit includes a rectangular receptacle housing, wedge lock, and three pins, along with the necessary components for assembling a connector. Wedge locks help maintain contact alignment and retention, while redundant silicone seals help protect the connection. Contacts can be inserted and removed by hand, supporting practical field service and repair work.

DT series connectors allow electrical designers to use multiple sizes of size 16 contacts within a single shell for applications using 18–14 AWG wire. The enclosed connector design is intended for wire-to-wire applications and offers a rugged solution for electrical connection repairs and assemblies. The connector system is rated IP68 and IP6K9K for ingress protection and complies with EU RoHS/ELV requirements and the UL-94 Recognized standard.

Key Features:

• Complete repair kit: Includes the main connector components needed to assemble a 2-position DT receptacle.
• 14–18 AWG application range: Supports DT series applications using size 16 contacts for compatible wire sizes.
• Sealed connector design: Redundant silicone seals help support protected electrical connections.
• Secure contact retention: Wedge locks help maintain contact alignment and retention.
• Serviceable contacts: Contacts are designed for hand insertion and removal.
• Ingress protection: Rated IP68 and IP6K9K for applicable connector assemblies.

Product Details:

• Brand: Pacer
• Part number: TDT04F-2RP
• Connector type: DT Deutsch rectangular receptacle repair kit
• Number of cavities: 2
• Contact size: Size 16, 13 amp
• Wire size: 14–18 AWG
• Contact type: Pins
• Housing: Plastic reinforced with glass fiber
• Operating temperature: -55°C to 125°C
• Contents: One 2-position receptacle, one 2-position wedge lock, and three pins
• Applications: Wire-to-wire connector assembly and repair
• Compliances: IP68, IP6K9K, EU RoHS/ELV, and UL-94 Recognized

Choose the Pacer TDT04F-2RP DT Deutsch Receptacle Repair Kit for a properly specified, serviceable connector solution for compatible 14–18 AWG wire-to-wire applications.
