Sea-Dog 2-Inch Gauge Power Socket Adapter Mounting Plate, Part 426101-1

2" Gauge Power Socket Adapter Mounting Plate

This instrument hole adapter is designed to install standard 1-1/8-in. gauges and meters into 2 in. instrument dash panel holes. The socket adapter is installed by placing the face plate in front of the dashboard and then inserting the socket/meter in the hole with the washer behind.

Features:

• Designed with D-flats to prevent gauges from spinning, the assembly is held in place by the socket/meter nut for a clean, finished look
• Constructed of UV-resistant injection-molded nylon

Specifications:

• Face Plate Outer diameter: 2-3/16 in.
• Face Plate Inner Diameter: 1-3/16 in.
• Face Plate Thickness: 3/16 in.
• Height: 2 in.
• Washer Inner Diameter: 1-1/16 in.
• Washer Thickness: 1/8 in.
• Weight: 0.04

WARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov.

Sea-Dog 2-Inch Gauge Power Socket Adapter Mounting Plate makes it easier to install standard 1-1/8-inch gauges and meters in 2-inch instrument dash panel holes. Designed for marine dashboards and instrument panels, this adapter provides a clean, finished installation by securing the gauge or meter between the front face plate and rear washer.

The Sea-Dog 426101-1 gauge adapter features D-flats that help prevent the installed gauge from spinning during use. The assembly is held in place by the socket or meter nut, creating a stable fit without adding unnecessary complexity to the installation. Its UV-resistant injection-molded nylon construction is suited to applications where the mounting plate may be exposed to sunlight.

Key Features:

• Gauge hole adapter: Installs standard 1-1/8-inch gauges and meters into 2-inch instrument dash panel holes.
• Anti-rotation design: D-flats help keep the gauge or meter from spinning after installation.
• Secure assembly: Face plate and washer fit around the dashboard panel and are held in place by the socket or meter nut.
• UV-resistant construction: Injection-molded nylon is designed to resist ultraviolet exposure.
• Finished appearance: The mounting plate provides a neat, clean look around the installed instrument.

Product Details:

• Brand: Sea-Dog
• Part number: 426101-1
• Product type: Gauge power socket adapter mounting plate
• Material: UV-resistant injection-molded nylon
• Face plate outer diameter: 2-3/16 inches
• Face plate inner diameter: 1-3/16 inches
• Face plate thickness: 3/16 inch
• Height: 2 inches
• Washer inner diameter: 1-1/16 inches
• Washer thickness: 1/8 inch
• Weight: 0.04 pound

Choose the Sea-Dog 426101-1 when you need a practical, clean-looking solution for adapting a standard gauge or meter to a larger instrument panel opening.

California Proposition 65 Warning: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov.
